Trek Fuel LX 9.8 Eagle 90 Gen 7
In stock at 2 shops in Vancouver
Prices and stock checked Oct 22.
Where to buy
2 shopsAbout this bike
Fuel LX 9.8 Eagle 90 is a rowdy carbon trail bike ready to slay steep descents and blast through wheel-gobbling terrain. Its OCLV Mountain Carbon frame partners with a Fox Factory 38 fork and DHX2 coil shock (160mm rear, 170mm front) for going all-out on the wiliest lines on the mountain. A mechanical SRAM Eagle 90 transmission gives you reliable shifts without the fuss of electronics, and 4-piston SRAM Maven Bronze brakes deliver power you can count on.
Technical Specifications
- Specification
- Details
Show full description and specs
Frame: OCLV Mountain Carbon, internal storage, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, adaptable travel 145mm-160mm
Fork: Fox Factory 38, Float EVOL air spring, GRIP X2 damper, 44mm offset, Boost 110, 15mm Kabolt X axle, 170mm travel
- Shock
- Fox DHX2, 205mm x 65mm
- Handlebar
- Race Face ERA, carbon, 35mm, 27.5mm rise, 800mm width
- Grips
- Trek Line Elite, lock-on
- Stem
- Bontrager Elite, 35mm, 0 degree, 45mm length
- Shifters
- SRAM Eagle 90, 12 speed
- Rear Derailleur
- SRAM Eagle 90, T-Type
- Bottom Bracket
- SRAM DUB MTB Wide, 73mm, BSA threaded
- Chain
- SRAM GX Eagle, T-Type, 12 speed
- Cassette
- SRAM Eagle XS-1275, T-Type, 10-52, 12 speed
- Crankset
- SRAM Eagle 90, DUB, 30T steel, T-Type, 55mm chainline, 170mm length
- Chainring
- 30T
- Brakes
- SRAM Maven Bronze 4-piston hydraulic disc
- Brake Rotors
- SRAM HS2, 6-bolt, R: 180mm, F: 200mm
- Saddle
- Verse Short Pro, carbon rails, 145mm width
Seatpost: Bontrager Line Dropper, 170mm travel, MaxFlow, internal routing, 34.9mm, 450mm length
- Front Wheel
- Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, 29"
Rear Wheel: Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, SRAM XD freehub, Boost148, 12mm thru axle, 29''
Front Tire: Maxxis Assegai, tubeless ready, 3C, EXO+ casing, Maxxgrip, folding bead, 29x2.5''
Rear Tire: Maxxis Minion DHR II, tubeless ready, 3C, EXO+ casing, Maxxterra, folding bead, 29x2.5''
- Weight
- M - 15.37 kg / 33.89 lbs (with TLR sealant, no tubes)
