Orbea Muga 20 28mph

Bosch Speed Full-Power Assist

The Bosch Performance Line Speed CX drive unit delivers up to 85Nm of torque and Class 3 (28 mph) assistance with Bosch's renowned smooth, powerful, natural feel. The integrated 750Wh Bosch PowerTube battery delivers exceptional range, managed by the Bosch System Controller and Bosch's proven, reliable ecosystem. There's plenty of power to flatten climbs or haul a fully loaded bike.

Trail-Ready Capability

A 120mm Fox 34 Float air fork and grippy 29-inch Schwalbe Johnny Watts Hybrid Radial tires deliver real off-road composure, while a dropper seatpost lets you drop the saddle for steep or technical sections. An electronic Shimano CUES Di2 U8050 11-speed drivetrain shifts crisply across a wide 11-45t range.

Built to Carry & Commute

Orbea's patented four-position cockpit dials in the perfect fit, while a fully integrated StVZO lighting system, robust mudguards, and a rear carrier make the Muga ready for cargo, adventure, and everyday duty.

Available in three colorways: Metallic Rust / Diamond Black, Ivory White / Black, and Blue Stone / Diamond Black - in sizes S-XL.

Key Features

• Bosch Performance Line Speed CX motor (up to 85Nm) with integrated 750Wh PowerTube battery
• Class 3 / 28mph pedal-assist e-bike
• Aluminum Orbea Muga frame, 29-inch wheels, belt-drive compatible
• Fox 34 Float AWL Sport 120mm suspension fork
• Shimano CUES Di2 U8050 electronic 11-speed drivetrain (11-45t)
• Shimano MT420 hydraulic disc brakes, dropper seatpost
• Integrated StVZO lighting, mudguards, rear carrier compatible

Build Kit

Frame

Orbea Muga, Hydroformed Alloy 6061

Fork

Fox 34 Float AWL Sport 120mm

Motor

Bosch Performance Line Speed CX (up to 85Nm)

Battery

Bosch PowerTube 750Wh

Display

Bosch System Controller

Rear Derailleur

Shimano CUES Di2 U8050 11-Speed SGS

Shifter

Shimano CUES Di2

Cassette

Shimano CS-LG400 11-45t, 11-Speed

Chain

KMC eGlide

Brakes

Shimano MT420 Hydraulic Disc

Crank

Prowheel EB03 alloy

Wheels

Alloy, 29-inch, 32H

Tires

Schwalbe Johnny Watts Hybrid Radial TLR 60-622, reflective

Seatpost

Dropper (OC remote)

Saddle

Selle Royal Vivo Ergo

Lighting

Integrated StVZO front and rear

Sizing

Orbea recommended rider height by size (approximate):

• S: 153-172 cm (5'0"-5'8")
• M: 164-183 cm (5'5"-6'0")
• L: 176-195 cm (5'9"-6'5")

XL

187-206 cm (6'2"-6'9")

Frequently Asked

• How fast is the Orbea Muga 20? It's a Class 3 e-bike with pedal assist up to 28 mph.
• What motor and battery does it use? Bosch Performance Line Speed CX (up to 85Nm) with an integrated 750Wh Bosch…
