Class 3 e-bike with Bosch Performance Sport motor provides up to 65 Nm of torque and 300% support, max speed of up to 28 mph
1 x 9-speed Shimano Alivio groupset with trigger shifter

Cargo capacity: 50 kg on the rear rack, plus an additional 20 kg with optional front rack

Show full description and specs

Fits riders 160: 195 cm (5'3" - 6'5"), and also riders 145 - 180 cm (4'9" - 5'11") when equipped with a shorter, 350 mm seatpost
Lots of available kid- and cargo-carrying accessories to build your perfect setup
Ultra-low 490 mm standover height makes (dis)mounting and waiting at stops easier
Shimano hydraulic disc brakes for reliable stopping power, even when heavily loaded and riding fast
Proven safe and reliable: frame and fork are EFBE-tested up to the 150 kg (331 lb) Maximum Gross Vehicle Weight
UL 2849 certified Bosch e-bike system & EN 15194 compliant, European standard for Electrically Power Assisted Cycles (EPACs)

Frame & Build

Frame: Tern Quick Haul, patented design, 6061-AL, EFBE Tri-Test approved: 150 kg
Fork: Cargo, steel, EFBE approved: 150 kg
Cockpit: Speedlifter stem, 150 mm extension, 3D forged (31.8mm); low riser handlebar

Drivetrain & Motor

Motor: Bosch Performance Sport, 65 Nm torque, 300% support, max speed up to 28 mph (Class 3)

Battery: Bosch PowerPack 400 (400 Wh)
Range: 31.7-62.1 mi
Charger: Compact charger, 100-240V, 2A
Shifter: Shimano Alivio, 1 x 9-speed, trigger
Derailleur: Shimano Alivio Shadow
Cassette: Shimano 11-34T, 9-speed
Crankset: Tern custom, forged 6061-AL
Chain: KMC eBike, 9-speed
Gear Range: 31"-95" (2.45-7.57 m)

Brakes: Front & Rear: Shimano hydraulic disc, Wheels & Tires, Hubs: Shimano disc, front and rear, Rims: Kinetix Comp, disc-compatible

Tires: Schwalbe Big Apple, 55-406, puncture protection, Reflex

Capacity & Weight

Bike Weight: 23 kg (50.7 lb)
Max Gross Vehicle Weight: 150 kg (330.7 lb)
Max Rider Weight: 120 kg (264.6 lb)
Rear Rack Capacity: 50 kg
Optional Front Rack Capacity: 20 kg

Geometry

Overall Size: 172.5 x 70 x 102.5 cm (67.9 x 27.6 x 40.4 in)
Standover Height: 490 mm
Seatpost to Handlebar: 60-64 cm (23.6-25.2 in)
Saddle to Pedal: 68-110 cm (26.8-43.3 in)
Suggested Rider Height: 160-195 cm (5'3"-6'5"); 145-180 cm (4'9"-5'11") with optional 350 mm seatpost

One-size frame; figures via ternbicycles.com/nz/bikes/471/quick-haul-p9-sport (US-spec page uses the same base geometry, Class-3 28 mph Performance Sport motor tune). This Class 3 e-bike is speed-capped at 25 mph when shipped to New York City per local regulation.
